Mã sản phẩm: LW-D30A/LW-D100 Tình trạng: Hết hàng

  • Mô tả

  • Đánh giá

For Many Different Types of Soldering and Plastic Welding!

LW-D series of laser diode welders irradiates the laser emitted from the laser diode onto a plastic part and welds it in a non-contact manner.
This is an air-cooled, compact laser welding machine that can be easy operation. It is most suitable for soldering and plastic welding.

  • Applicable to Various Shapes and Material
    Three types of output mode are available(Profile, Continuous, Pulse)
  • Laser Output Waveform is Visualized
    Preset numerical data is converted into waveform and displayed
    Actual output waveform is trace displayed
  • Simple Operation
    Laser can be output immediately after switch ON
    Easy-to-operate jog dial is equipped
    Guide light to confirm laser output position is provided
  • Suitable to be Equipped on Automated Machine
    RS-232C, I/O equipped
    Various monitoring (alarm) functions
  • Desk Top Type
  • Compatible to Pb Free Solder
    Items LW-D30A LW-D100
    Max Rated Power 26W 100W
    Features
    • Small spot diameter and high power density
      In addition to the standard spot diameter model (MinΦ800μm), small spot diameter with optional lens (MinΦ400μm) is available, too
    • Light weight, air cooled, compact
      Small foot print contributes in securing work area and smaller size of the total machine
    • Output head is attached as standard
    • Completely air cooled with high output of maximum 100W
    • Small spot diameter and high power density
      In addition to the standard spot diameter model (fiber core diameter Φ400μm), small spot diameter model (fiber core diameter Φ200μm) is available, too

Specifications:

Items LW-D30A LW-D100
Wave Length 980 nm
Max Rated Power 26 W (Class 4) 100 W (Class 4)
Output Head Attached Sold Separately
Optical Fiber Core Diameter φ 400 μm Two types, Φ400 μm、Φ200 μm
Core Diameter When standard output head is used :
φ800 μm (WD 80 mm)
When additional option lens is used :
φ400 μm (WD 35 mm)		 When separately sold output head is used :
(imaging magnifi cation switchable between ×1 and ×2)
  • Fiber core diameter Φ400 μm type
    ×2 Φ800 μm / ×1 Φ400 μm
  • Fiber core diameter Φ200 μm type
    ×2 Φ400 μm / ×1 Φ200 μm
  • When×2 WD 185 mm / When×1 WD 83 mm
Guide Beam 635 nm
Output Condition 15 Data
Output Setting Range Current : 3.0 - 56.4 A (0.1 A step)
Power : 0.0 - 26.0 W (0.1 W step)		 Current : 0.10 - 10.30 A (0.01 A step)
Power : 0.0 - 100.0 W (0.1 W step)
Time Setting Range 0.000 - 99.999 s (1 ms step)
Interface I / O、RS-232C (max 57600 bps)
Output Mode CW output, Pulse output, Profi le waveform output (max 256 point setting)
Monitor Display LD drive current, Laser power (Digital display, Graphic display)
Alarm Function Interlock error, Control error, Over current error, Over power error, LD high temperature error, FET high temperature error
Cooling Method Air
Power Source AC 100 V ±10%、50/60 Hz AC 100 - 240 V ±10%、50/60 Hz
Max Power Consumption 800 W
Dimension / Weight W200×D430×H280 mm (excluding protrusion and optical system)
19 kg (excluding optical system)		 W435×D430×H255 mm (excluding protrusion and optical system)
30 kg (excluding optical system)
